Viair 400C Compressor Kit (12V, 33% Duty, Sealed) - 40040

400C Air Compressor Kit - 150 PSI / 2.54 CFM

For all your air compression needs on the job or simply for everyday life, choose the powerful Viair 150 PSI 400C Air Compressor Kit. This electric air compressor is great for air tools, vehicle tires, and more. It includes a 0.025" stainless steel braided leader hose with check valve. It can be used with an air tank up to 5 gallons. It comes complete with mounting hardware and installation instruction to make installing a breeze. Choose quality equipment and get the job done quickly and safely with the Viair 150 PSI 400C Air Compressor Kit.

FEATURES

• 150 PSI Max Working Pressure, engine must be running during use.


• 2.54 CFM Free Flow @ 0 PSI.


• This unit is designed to be mounted onto the vehicle for use in an onboard air system or air suspension system. Can also be used to power air horns.


• All VIAIR Compressors are oil-less, brush DC, permanent magnetic motors.


• Color : Silver

SPECIFICATIONS

• 150 PSI / 2.54 CFM


• 12-Volt


• Duty Cycle: 33% @ 100 PSI


• Max. Working Pressure: 150 PSI


• Max. Air Tank Size: 5.0 Gallon


• Max. Amp Draw: 32 Amps


• Ingress Protection Rating: IP67


• Dimensions: 9" x 4" x 6.75"


• Weight: 8.65 lbs.


• Part Number: 40040

INCLUDES

• Check Valve


• Vibration Isolators


• Mounting Hardware


• Stainless Steel Braided Leader Hose


• Air Line for Remote Mount Air Filter


• Remote Mount Air Filter Assembly


• (2) Replacement Air Filter Elements


• Installation Instructions

NOTE: Use thread sealant for proper installation. PTFE tape is not recommended. Properly sealed, recommended torque is 12 to 15 ft. lbs.
